Запчасти головка цилиндров(№88-) самосвалы hd985-5 s/n 1021-up Komatsu



|$2 6215-11-1102 CYLINDER HEAD ASS'Y
|$3 6215-11-1101 CYLINDER HEAD ASS'Y
1 HEAD,CYLINDER
2 6216-11-1330 INSERT,INTAKE VALVE (STD)
2 6216-19-1330 INSERT, 0.25MM,INTAKE VALVE (OS)
2 6216-18-1330 INSERT, 0.50MM,INTAKE VALVE (OS)
2 6216-17-1330 INSERT, 0.75MM,INTAKE VALVE (OS)
2 6216-16-1330 INSERT, 1.00MM,INTAKE VALVE (OS)
3 6210-11-1321 INSERT,EXHAUST VALVE (STD)
3 6210-19-1321 INSERT, 0.25MM,EXHAUST VALVE (OS)
3 6210-18-1321 INSERT, 0.50MM,EXHAUST VALVE (OS)
3 6210-17-1321 INSERT, 0.75MM,EXHAUST VALVE (OS)
3 6210-16-1321 INSERT, 1.00MM,EXHAUST VALVE (OS)
4 6212-16-1440 GUIDE,VALVE
5 6210-11-1150 PIPE
6 07000-73025 O-RING (K1)
7 6162-13-1150 PLUG,EXPANSION
8 07046-41810 PLUG,EXPANSION
9 6215-81-9510 PLUG
10 6215-81-9710 O-RING (K1)
11 04020-00820 PIN,DOWEL
12 6210-11-1140 GUIDE,CROSSHEAD
13 6215-41-4110 VALVE,INTAKE
14 6215-41-4220 VALVE,EXHAUST
15 6212-41-4540 SEAL,VALVE STEM (K1)
16 6210-41-4530 SEAT,SPRING LOWER
17 6210-41-4510 SEAT,SPRING UPPER
18 6136-41-4520 COTTER,VALVE
19 6210-41-4440 SPRING,INNER
20 6210-41-4430 SPRING,OUTER
21 6210-41-5620 CROSSHEAD
22 6210-41-5641 SCREW
23 6162-43-5630 NUT
24 6210-17-1814 GASKET,HEAD (K1)
25 6210-11-1820 GROMMET,OIL
26 6210-11-1831 GROMMET,OIL
27 6210-11-1840 GROMMET,OIL
28 6210-11-1962 GROMMET,WATER
29 6210-11-1952 GROMMET,WATER
30 6210-11-1940 GROMMET,WATER
24 6210-19-1814 GASKET,HEAD
25 6210-19-1820 GROMMET,OIL
26 6210-19-1831 GROMMET,OIL
27 6210-19-1840 GROMMET,OIL
28 6210-19-1962 GROMMET,WATER
29 6210-19-1952 GROMMET,WATER
30 6210-19-1940 GROMMET,WATER
31 6210-11-1610 BOLT,HEAD
32 01438-01020 BOLT,HEAD
1
2
3
4
4
5
6
7
7
7
7
8
9
10
11
12
12
13
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
25
26
27
28
29
30
24
25
26
27
28
29
30
31
32
