Запчасти рукоять, mm, рукоять экскаваторы pc290nlc-10 s/n 15001-up Komatsu



|$1 206-944-K425 Arm Assembly
1 206-944-K432 Arm
2 20Y-970-3570 Bracket
3 20Y-70-K6410 Seat
4 206-62-K2740 Bracket
5 20Y-62-K5830 Bracket
6 20Y-62-K7290 Seat
7 20Y-70-31272 Bushing
8 20Y-70-32410 Bushing
9 21K-70-12161 Bushing
10 07020-00000 Fitting, Grease
11 07145-00090 Seal, Dust
12 20Y-70-23230 Seal, Dust
13 206-70-22250 Pin
14 205-70-66581 Plate
15 01010-81230 Bolt
16 01643-31232 Washer
17 21K-70-71650 Spacer, T=1.0mm
18 206-70-22260 Pin
19 205-70-66581 Plate
20 01010-81230 Bolt
21 01643-31232 Washer
22 21K-70-71650 Spacer, T=1.0mm
23 21K-70-71660 Spacer, T=2.0mm
24 707-H1-X0230 Cylinder Assembly
17
13
11
14
7
16
15
7
22
23
11
4
6
23
22
10
1
5
2
18
12
19
9
24
21
20
3
9
12
10
12
8
8
12
