Запчасти управляющ. клапан(№-) погрузчики гусеничные d75s-2 s/n 1004-up Komatsu



|$0 145-60-00012 TANK ASS'Y
|$1 145-60-00011 TANK ASS'Y
|$2 145-60-00012 TANK ASS'Y
|$3 145-60-00011 TANK ASS'Y
|$4 145-60-00010 TANK ASS'Y
|$5 145-60-00052 VALVE ASS'Y
|$6 145-60-00051 VALVE ASS'Y
|$7 145-60-00052 VALVE ASS'Y
|$8 145-60-00051 VALVE ASS'Y
|$9 145-60-00050 VALVE ASS'Y
|$10 145-60-00041 VALVE ASS'Y
|$11 145-60-00040 VALVE ASS'Y
1 141-60-12810 BODY
2 145-60-12151 SPOOL
3 145-60-32310 SPOOL
3 145-60-12311 SPOOL
4 170-78-14120 VALVE,CHECK
5 170-78-14130 SPRING
6 145-60-12120 SEAT
7 07000-03035 O-RING (KIT)
8 170-78-14150 PLATE
9 01010-31235 BOLT
10 01602-01236 WASHER
11 01000-30825 BOLT
12 01602-00825 WASHER
13 170-78-14181 SPACER
14 145-60-12170 SPRING
15 170-78-14210 WASHER
16 01010-31222 BOLT
17 01602-01236 WASHER
18 145-60-12160 RETAINER
19 01010-31235 BOLT
20 01602-01236 WASHER
21 145-60-12330 SPACER
22 145-60-12340 SPRING
23 145-60-12350 SPACER
24 145-60-12361 RETAINER
25 04260-01270 BALL
26 145-60-12371 SPACER
27 131-60-42160 SPRING
|$40 145-60-05020 SHIM ASS'Y
28 145-60-12390 SHIM, 0.5MM
29 145-60-12411 RETAINER
30 145-60-12420 LOCK
31 04065-06020 RING
32 01010-31235 BOLT
33 01602-01236 WASHER
|$47 141-60-00141 VALVE ASS'Y,VACUUM CHECK
|$48 141-60-00140 VALVE ASS'Y,VACUUM CHECK
|$49 141-60-00141 VALVE ASS'Y,VACUUM CHECK
|$50 141-60-00140 VALVE ASS'Y,VACUUM CHECK
|$51 VALVE ASS'Y
|$52 141-60-00271 HOUSING ASS'Y
|$53 VALVE ASS'Y
|$54 141-60-00271 HOUSING ASS'Y
34 141-60-12821 HOUSING
34 HOUSING
34 141-60-12821 HOUSING
34 HOUSING
35 145-60-32282 VALVE
35 145-60-32282 VALVE
36 145-60-32530 VALVE
|$62 141-60-00261 COVER ASS'Y
|$63 141-60-00261 COVER ASS'Y
37 COVER
37 COVER
|$66 141-60-12832 COVER
|$67 141-60-12832 COVER
38 PISTON
38 PISTON
39 170-78-14380 SPRING
40 07000-03045 O-RING (KIT)
41 07000-03038 O-RING (KIT)
42 141-60-12840 TUBE
43 141-60-12910 VALVE
44 01040-31025 BOLT
45 01602-01030 WASHER
45 01602-01030 WASHER
45 01602-01030 WASHER
45 01602-01030 WASHER
46 01040-31055 BOLT
46 01040-31055 BOLT
47 01040-31045 BOLT
47 01040-31045 BOLT
47 01040-31045 BOLT
47 01040-31045 BOLT
48 01602-01030 WASHER
48 01602-01030 WASHER
49 07042-00108 PLUG
49 07042-00108 PLUG
50 01041-31245 BOLT
50 01040-31245 BOLT
50 01041-31200 BOLT
50 01041-31245 BOLT
50 01040-31245 BOLT
50 01041-31200 BOLT
51 01602-01236 WASHER
52 141-60-12590 PLUG
52 141-60-12590 PLUG
53 141-60-12580 NUT
53 141-60-12580 NUT
54 141-60-12562 SPRING,LARGE
54 141-60-12562 SPRING,LARGE
55 141-60-12571 SPRING,SMALL
55 141-60-12571 SPRING,SMALL
56 07000-02015 O-RING (KIT)
56 07000-02015 O-RING (KIT)
57 07000-03030 O-RING (KIT)
|$108 141-60-00151 CHECK VALVE ASS'Y,CHECK
|$109 141-60-00292 HOUSING ASS'Y
58 141-60-12850 HOUSING
59 145-60-32530 VALVE
60 141-60-12890 VALVE
|$113 141-60-00281 COVER ASS'Y
61 141-60-12860 COVER
62 145-60-32541 PISTON
63 170-78-14380 SPRING
64 07000-03045 O-RING (KIT)
65 07000-03038 O-RING (KIT)
66 141-60-12562 SPRING,LARGE
67 141-60-12571 SPRING,SMALL
68 141-60-12580 NUT
69 141-60-12590 PLUG
70 07040-00108 PLUG
71 07000-22015 O-RING (KIT)
72 01040-31045 BOLT
73 01040-31080 BOLT
74 01602-01030 WASHER
75 01041-31200 BOLT
75 01011-31200 BOLT
76 01602-01236 WASHER
77 07000-23030 O-RING (KIT)
78 141-60-12920 PLUG
79 145-60-12180 BRACKET
80 170-78-14230 SHAFT
81 145-60-12190 BEARING
82 01640-01826 WASHER
83 01511-01813 NUT
84 04050-04030 PIN
85 01602-01236 WASHER
86 01040-31230 BOLT
86 01010-31230 BOLT
87 170-78-14250 LEVER
88 04213-01040 YOKE
89 04205-01028 PIN
90 04050-03015 PIN
91 07000-02018 O-RING (KIT)
92 07000-23045 O-RING (KIT)
93 07000-02015 O-RING (KIT)
94 01040-31230 BOLT
94 01010-31230 BOLT
95 01602-01236 WASHER
96 141-60-12870 BAFFLE
97 141-60-18550 FLANGE
98 01040-31440 BOLT
99 01602-01442 WASHER
99 140-60-00034 RELIEF VALVE ASS'Y,RELIEF
99 135-60-00080 HOUSING ASS'Y
100 135-60-12120 HOUSING
101 135-60-12220 VALVE
102 07000-03048 O-RING (KIT)
103 170-64-12730 SPRING
104 135-60-12132 BODY
105 135-60-12142 SEAT
106 135-60-12152 VALVE
106 135-60-12151 VALVE
107 135-60-12161 SPRING
108 170-64-00100 SHIM ASS'Y
108 170-64-12810 SHIM, 0.1MM
108 SHIM, 0.2MM
108 SHIM, 0.5MM
108 SHIM, 1.0MM
109 135-60-12181 PLUG
110 01041-31405 BOLT
111 01602-01442 WASHER
