| |$0 | 6261-31-1200 | Crankshaft Assembly | |
| 1 | Crankshaft | ||
| 2 | 6150-31-1130 | Key | |
| 3 | 6210-31-1120 | Gear | |
| 3 | 6261-21-8000 | Metal Assembly | |
| 3 | 6261-21-8010 | Main Metal Assembly, Standard | |
| 3 | 6261-29-8010 | Main Metal Assembly, Undersize 0.25mm | |
| 3 | 6261-28-8010 | Main Metal Assembly, Undersize 0.50mm | |
| 3 | 6261-27-8010 | Main Metal Assembly, Undersize 0.75mm | |
| 3 | 6261-26-8010 | Main Metal Assembly, Undersize 1.00mm | |
| 4 | Metal, Upper, Standard | ||
| 4 | Metal, Upper, Undersize 0.25mm | ||
| 4 | Metal, Upper, Undersize 0.50mm | ||
| 4 | Metal, Upper, Undersize 0.75mm | ||
| 4 | Metal, Upper, Undersize 1.00mm | ||
| 5 | Metal, Lower, Standard | ||
| 5 | Metal, Lower, Undersize 0.25mm | ||
| 5 | Metal, Lower, Undersize 0.50mm | ||
| 5 | Metal, Lower, Undersize 0.75mm | ||
| 5 | Metal, Lower, Undersize 1.00mm | ||
| 5 | 6210-21-8050 | Thrust Metal Assembly, Standard | |
| 5 | 6210-29-8050 | Thrust Metal Assembly, Oversize 0.25mm | |
| 5 | 6210-28-8050 | Thrust Metal Assembly, Oversize 0.50mm | |
| 5 | 6210-27-8050 | Thrust Metal Assembly, Oversize 0.75mm | |
| 5 | 6210-26-8050 | Thrust Metal Assembly, Oversize 1.00mm | |
| 6 | Metal, Thrust, Standard | ||
| 6 | Metal, Thrust, Oversize 0.25mm | ||
| 6 | Metal, Thrust, Oversize 0.50mm | ||
| 6 | Metal, Thrust, Oversize 0.75mm | ||
| 6 | Metal, Thrust, Oversize 1.00mm | ||
| 7 | 04020-01228 | Pin, Dowel | |
| 8 | 6211-31-1420 | Pin |
