| 1 | 561-54-8A211 | Hood | |
| 2 | 08037-03614 | Grommet | |
| 3 | 08037-05016 | Grommet | |
| 4 | 561-54-8A221 | Cover | |
| |$4 | 561-54-8A120 | Hinge,Welded | |
| 5 | 01010-81025 | Bolt | |
| 6 | 01643-31032 | Washer | |
| 7 | 569-54-81251 | Stay | |
| 8 | 01010-80820 | Bolt | |
| 9 | 01643-30823 | Washer | |
| 10 | 207-57-11260 | Washer | |
| 11 | 23S-54-27190 | Seal | |
| 12 | 561-46-81681 | Stay | |
| 13 | 01643-31645 | Washer | |
| 14 | 01010-81650 | Bolt | |
| 15 | 561-54-86951 | Shim, T=1.0mm | |
| 16 | 01010-81225 | Bolt | |
| 17 | 01643-31232 | Washer | |
| 18 | 09415-03614 | Cap | |
| 19 | 561-54-61290 | Seal | |
| 20 | 561-54-81270 | Seal |
