| 1 | AHEK4138 | Sensor | |
| 2 | AHXC0417 | Wiring Harness | |
| 3 | 562-61-32240 | Bracket | |
| 4 | 01643-32060 | Washer | |
| 5 | 01010-82070 | Bolt | |
| 6 | 562-61-32250 | Cover | |
| 7 | 01010-81020 | Bolt | |
| 8 | 01643-31032 | Washer | |
| 9 | 562-61-32260 | Cover | |
| 10 | 562-61-32270 | Cover | |
| 11 | 01010-81025 | Bolt | |
| 12 | 01643-31032 | Washer | |
| 13 | 562-61-32280 | Cover | |
| 14 | 01010-81020 | Bolt | |
| 15 | 01643-31032 | Washer | |
| 16 | 562-61-32290 | Plate | |
| 17 | 01010-81020 | Bolt | |
| 18 | 01643-31032 | Washer | |
| 19 | 04434-51010 | Clip | |
| 20 | 01010-81016 | Bolt | |
| 21 | 01643-31032 | Washer | |
| 22 | 562-06-33140 | Cover | |
| 23 | 07283-36365 | Clip, Pipe | |
| 24 | 01643-31032 | Washer | |
| 25 | 01597-01009 | Nut | |
| 26 | 04434-52711 | Clip | |
| 27 | 07095-20420 | Cushion | |
| 28 | 01010-81020 | Bolt | |
| 29 | 01643-31032 | Washer |
