| 1 | 150-952-7160 | Grommet | |
| 2 | 04434-51312 | Clip | |
| 3 | 01010-81225 | Bolt | |
| 4 | 01643-31232 | Washer | |
| 5 | 04434-53412 | Clip | |
| 6 | 195-979-3570 | Collar | |
| 7 | 01011-81200 | Bolt | |
| 8 | 01643-31232 | Washer | |
| 9 | 04434-53412 | Clip | |
| 10 | 195-33-11220 | Spacer | |
| 11 | 01010-81245 | Bolt | |
| 12 | 01643-31232 | Washer | |
| 13 | 04434-53412 | Clip | |
| 14 | 207-04-77121 | Bracket | |
| 15 | 01010-81245 | Bolt | |
| 16 | 01643-31232 | Washer | |
| 17 | 21T-62-76850 | Clip | |
| 18 | 07095-01034 | Cushion | |
| 19 | 01010-81225 | Bolt | |
| 20 | 01643-31232 | Washer | |
| 21 | 01011-81040 | Bolt | |
| 22 | 01643-31032 | Washer | |
| 23 | 6151-51-5490 | Spacer | |
| 24 | 02762-00335 | Hose | |
| 25 | 02762-00432 | Hose, Face Seal Type | |
| 26 | 11Y-09-11140 | Clip | |
| 27 | 01010-81240 | Bolt | |
| 28 | 01643-31232 | Washer |
