| |$0 | 209-70-00471 | Arm Assembly | |
| 1 | Arm | ||
| 2 | 209-944-5230 | Bushing | |
| 3 | 07020-00000 | Fitting, Grease | |
| 4 | 209-72-53170 | Bushing | |
| 5 | 07020-00000 | Fitting, Grease | |
| 6 | 209-70-51190 | Bushing | |
| 7 | 209-944-5240 | Seal | |
| 8 | 209-72-12211 | Seal | |
| 9 | 209-72-11261 | Seal | |
| 10 | 209-70-71331 | Pin | |
| 11 | 21N-70-11230 | Plate | |
| 12 | 01010-81640 | Bolt | |
| 13 | 01643-31645 | Washer | |
| 14 | 21N-72-11152 | Pin | |
| 15 | 21N-72-11230 | Shim, T=1.0mm | |
| 16 | 21N-70-11230 | Plate | |
| 17 | 01010-81640 | Bolt | |
| 18 | 01643-31645 | Washer |
