Запчасти гидротрансформатор и трансмиссия, входн. вал (№9-) погрузчики колесные wa470-6a s/n 90216-up (for north america) Komatsu



|$0 714-07-40011 Transmission Assembly
|$1 714-07-40010 Transmission Assembly
1 714-07-42262 Shaft
2 17A-22-47360 Plug
3 07043-70211 Plug
4 714-07-42511 Gear
5 714-07-47713 Cover
6 01010-81285 Bolt
7 01643-31232 Washer
8 714-07-46122 Spacer
9 04071-00140 Ring, Snap
10 714-07-49640 Bearing
11 714-07-49410 Bearing
12 714-07-49420 Bearing
13 714-12-39210 Seal Ring, (Kit : K01, K02)
14 714-21-19810 Seal Ring, (Kit : K01, K02)
15 714-12-39230 Seal Ring, (Kit : K01, K02)
16 714-12-39230 Seal Ring, (Kit : K01, K02)
17 419-15-12122 Ring, (Kit : K01, K02)
18 714-07-43211 Gear
19 714-07-49610 Bearing
20 714-07-49670 Plate
21 234-15-23280 Holder
22 01011-61615 Bolt
23 01643-31645 Washer
24 714-07-46320 Spacer
25 04071-00150 Ring, Snap
26 714-07-43223 Gear
27 714-07-43323 Shaft
28 714-07-46310 Plate
29 04065-04518 Ring, Snap
30 714-12-39360 Bearing
31 714-07-49661 Bearing
17
1
22
23
31
30
28
29
27
7
6
24
25
26
21
20
19
18
16
15
13
12
11
10
9
8
2
4
5
9
3
14
