| 1 | 198-54-75411 | Plate | |
| 2 | 01010-83070 | Bolt | |
| 3 | 01643-33080 | Washer | |
| 4 | 198-54-75231 | Plate | |
| 5 | 01010-83375 | Bolt | |
| 6 | 01643-33380 | Washer | |
| 7 | 198-911-7512 | Case | |
| 8 | 14X-911-7750 | Filter | |
| 9 | 198-911-7551 | Bracket | |
| 10 | 195-Z11-5880 | Clamp | |
| 11 | 01010-81225 | Bolt | |
| 12 | 01643-31232 | Washer | |
| 13 | 198-54-75422 | Bracket | |
| 14 | 01010-81280 | Bolt | |
| 15 | 01643-31232 | Washer | |
| 16 | 01010-81225 | Bolt | |
| 17 | 01643-31232 | Washer | |
| 18 | 21T-979-6570 | Hose | |
| 19 | 14X-911-7670 | Clamp | |
| 20 | 198-911-7750 | Clip | |
| 21 | 01010-81220 | Bolt | |
| 22 | 01643-31232 | Washer | |
| 23 | 195-33-11220 | Spacer | |
| 24 | 01010-81250 | Bolt | |
| 25 | 01643-31232 | Washer | |
| 26 | 195-54-77340 | Cover | |
| 27 | 01010-80825 | Bolt | |
| 28 | 01643-30823 | Washer |
