Запчасти ковш (№-) экскаваторы pc600lc-8e0 s/n 65001-up Komatsu
|
|
1 |
21M-939-2352 |
Bucket
|
|
|
2 |
21M-939-2261 |
Adapter,Welded
|
|
|
3 |
21M-939-2271 |
Adapter,Welded
|
|
|
4 |
21M-939-2360 |
Plate,Welded
|
|
|
5 |
21M-939-2370 |
Plate,Welded
|
|
|
6 |
21M-939-2380 |
Plate,Welded
|
|
|
7 |
21M-939-2252 |
Shroud,Welded
|
|
|
8 |
21M-939-2410 |
Plate,Welded
|
|
|
9 |
21M-939-2420 |
Plate,Welded
|
|
|
10 |
21M-939-2610 |
Plate,Welded
|
|
|
11 |
21M-939-2620 |
Plate,Welded
|
|
|
12 |
21M-939-2630 |
Plate,Welded
|
|
|
13 |
21M-939-2281 |
Tooth
|
|
|
14 |
21M-939-2291 |
Pin Assembly
|
|
|
15 |
209-70-54171 |
Cover
|
|
|
16 |
01010-82480 |
Bolt
|
|
|
17 |
01643-32460 |
Washer
|
|
|
18 |
209-70-54160 |
Bushing
|
|
|
19 |
209-72-54220 |
Bushing
|
|
|
20 |
209-70-00082 |
Shim Assembly
|
|
|
20 |
|
Shim, T=1.0mm
|
|
|
20 |
|
Shim, T=0.5mm
|
1
4
6
7
5
12
3
2
8
10
8
9
11
16
9
19
18
17
20
15
13
14
