Запчасти механизм поворота и мотор, прав. (№-) экскаваторы pc600lc-8e0 s/n 65001-up Komatsu



1 01010-81460 Bolt
2 01643-31445 Washer, Flat
3 22U-26-21280 Ring
4 07049-01822 Plug
5 21M-26-21170 Case
6 06000-22222 Bearing
7 06000-22324 Bearing
8 207-26-54263 Cover
9 01010-81040 Bolt
10 01643-31032 Washer
11 207-26-61210 Seal
12 21M-26-11180 Shaft
13 207-26-62150 Coupling
14 207-26-54230 Plate
15 205-32-51211 Bolt
16 20Y-27-22170 Carrier
17 20Y-27-22140 Gear
18 20Y-27-22220 Bearing
19 20Y-27-21250 Washer, Thrust
20 20Y-27-21230 Pin
21 20Y-27-21290 Pin
22 207-26-62190 Gear
23 20Y-27-13310 Washer, Thrust
24 20Y-27-22240 Washer, Thrust
25 21M-26-11261 Gear
26 21M-26-11150 Carrier
27 21M-26-11140 Gear
28 20Y-27-22210 Bearing
29 20Y-27-21240 Washer, Thrust
30 20Y-27-21220 Pin
31 20Y-27-21280 Pin
32 21M-26-11190 Plate
33 21M-26-21130 Gear
34 20Y-27-21310 Washer
35 21M-26-11161 Cover
36 20Y-27-13281 Bolt
37 01643-31645 Washer
38 208-27-61350 Button
39 20Y-27-22280 O-ring
40 07049-02430 Plug
41 21M-26-11270 Elbow
42 02896-11018 O-ring
43 02782-10628 Elbow
44 02896-11018 O-ring
45 02762-006A4 Hose
46 07730-50004 Valve, Drain
47 07002-12434 O-ring
48 21M-26-21180 Gauge
49 21M-26-21220 Filler
45
43
9
12
10
8
11
7
47
5
14
13
6
25
15
22
23
24
38
16
32
21
19
17
18
19
20
30
29
28
27
29
49
48
26
31
36
37
35
33
34
2
39
1
3
46
41
4
44
42
40
