| 1 | 6217-61-6330 | Gasket | |
| 2 | 6217-61-6340 | Gasket | |
| 3 | 6217-61-6350 | Elbow | |
| 4 | 01437-11025 | Bolt | |
| 5 | 01437-11080 | Bolt | |
| 6 | 07043-A0415 | Plug | |
| 6 | 6261-61-1202 | Water Pump Assembly | |
| 6 | 6261-61-1201 | Water Pump Assembly | |
| 7 | 6261-61-1210 | Impeller | |
| 8 | Case | ||
| 9 | 6261-61-1310 | Shaft | |
| 10 | 6212-61-1410 | Gear | |
| 11 | 6210-61-1520 | Seal | |
| 12 | 04065-07225 | Ring, Snap | |
| 13 | 6212-61-1370 | Spacer | |
| 14 | 6212-61-1380 | Spacer | |
| 15 | 06000-06305 | Bearing, Ball | |
| 16 | 06030-06306 | Bearing, Ball | |
| 17 | 6210-61-1350 | Flange | |
| 18 | 6261-61-1150 | Cover | |
| 19 | 6261-61-1190 | Ring, Snap | |
| 20 | 6261-61-1170 | O-ring | |
| 21 | 6211-61-1533 | Seal, Water | |
| 22 | 07062-00000 | Valve, Air Blow | |
| 23 | 6212-61-1330 | Ring | |
| 24 | 07043-01019 | Plug, Taper | |
| 24 | 07043-A1019 | Plug, Taper | |
| 25 | 02720-10104 | Plug, Tapered | |
| 26 | 01435-01075 | Bolt | |
| 27 | 01435-01095 | Bolt | |
| 28 | 07000-72070 | O-ring | |
| 29 | 07000-72115 | O-ring | |
| 30 | 6210-61-6441 | Gasket | |
| 31 | 6261-61-6260 | Tube | |
| 32 | 6261-61-6270 | Bracket | |
| 33 | 01435-01020 | Bolt | |
| 34 | 01435-01025 | Bolt |
