Запчасти сиденье оператора, внутр. части (№9-) погрузчики колесные wa480-6 s/n 90216-up (for north america) Komatsu



|$0 421-57-41110 Seat Assembly
1 421-57-31510 Cushion
2 421-57-31520 Backrest
3 421-57-31541 Armrest
4 421-57-31550 Lifter Assembly
4 421-57-31620 Cover Assembly
5 421-57-31630 Cover,L.H.
6 421-57-31820 Cap
7 421-57-31640 Cover,R.H.
8 421-57-31820 Cap
8 421-57-31650 Knob Assembly
9 421-57-31660 Knob, Tilt, Front
10 421-57-31670 Knob, Tilt, Rear
11 421-57-31680 Knob, Reclining
12 421-57-31690 Knob, Slide
13 421-57-31740 Switch, Lumber
14 421-57-31750 Switch, Air Suspension
15 421-57-31560 Suspension Assembly
16 421-57-31710 Spring Assembly
17 421-57-31720 Compressor Assembly
18 421-57-31730 Damper
18 421-57-31760 Wiring Harness Assembly
19 421-57-31770 Wiring Harness
20 421-57-31780 Wiring Harness
21 421-57-31790 Wiring Harness
22 421-57-31810 Relay
23 421-57-31570 Cover
24 421-57-31580 Clip
25 421-57-31590 Adjuster, Seat
26 421-57-31610 Headrest
8
6
16
18
22
17
10
13
12
7
9
21
19
20
24
1
25
2
4
23
15
26
3
5
11
14
