| 1 | 23A-952-7741 | Duct | |
| 2 | 01010-80620 | Bolt | |
| 3 | 01643-30623 | Washer | |
| 4 | 01010-80616 | Bolt | |
| 5 | 01643-30623 | Washer | |
| 6 | 20Y-53-12310 | Collar | |
| 7 | 23A-952-7750 | Duct | |
| 8 | 01010-80620 | Bolt | |
| 9 | 01643-30623 | Washer | |
| 10 | 20Y-53-12310 | Collar | |
| 11 | 23A-952-7760 | Duct | |
| 12 | 23B-952-7220 | Seal | |
| 13 | 01010-80620 | Bolt | |
| 14 | 01643-30623 | Washer | |
| 15 | 20Y-53-12310 | Collar | |
| 16 | 23B-952-7250 | Seal | |
| 17 | 23B-925-8680 | Plate | |
| 18 | 01245-00620 | Screw | |
| 19 | 01643-70623 | Washer | |
| 20 | 421-07-12512 | Grille | |
| 21 | 23B-07-84221 | Panel | |
| 22 | 01023-70414 | Screw | |
| 23 | 23B-952-8122 | Wiring Harness | |
| 23 | 23B-952-8121 | Wiring Harness | |
| 24 | 04434-51712 | Clip | |
| 25 | 23B-07-84191 | Louver | |
| 26 | 23B-07-84180 | Screw |
