Запчасти пол, крышкаand tray (№-) грейдеры gd675-6 s/n 60001-up Komatsu



1 23B-54-82212 Cover
2 423-54-42790 Band
3 23B-54-85710 Cover
4 23B-54-85740 Cover
5 01010-D0820 Bolt
6 01643-70823 Washer
7 56D-54-35320 Washer
8 56D-54-35310 Collar
9 23S-55-51970 Washer
10 01240-00625 Screw, Hexagon Socket Head
11 23B-54-82771 Sheet
12 23B-54-82741 Cover
13 01643-70623 Washer
14 01245-00616 Screw
15 23B-54-82751 Cover
16 235-54-11540 Knob
17 23B-54-85210 Seal
18 23B-54-82231 Bracket
19 23B-54-82191 Bracket
20 23B-54-82182 Cover
21 01010-D0816 Bolt
22 01643-70823 Washer
23 56D-54-35320 Washer
24 23B-54-85180 Washer
25 56D-54-35310 Collar
26 23S-55-51970 Washer
27 01240-00620 Screw
28 23B-54-84771 Cover
29 01010-D0816 Bolt
30 01643-70823 Washer
7
8
10
4
22
1
21
30
29
28
27
26
25
24
19
22
21
20
19
17
16
15
13
14
12
11
10
9
8
7
6
5
3
2
9
6
11
5
18
23
25
26
27
21
22
