| 1 | 418-54-32940 | Bracket | |
| 2 | 01010-80816 | Bolt | |
| 3 | 01643-30823 | Washer | |
| 4 | 418-877-3210 | Cover | |
| 5 | 01225-70616 | Screw, Philips Head | |
| 6 | 418-926-3490 | Washer | |
| 7 | 418-877-3271 | Bracket | |
| 8 | 01010-80612 | Bolt | |
| 9 | 01643-30623 | Washer | |
| 10 | 419-54-32650 | Awning | |
| 11 | 419-54-32710 | Plate | |
| 12 | 01010-80612 | Bolt | |
| 13 | 01643-30623 | Washer | |
| 14 | 419-54-32613 | Cover,Upper | |
| 15 | 421-09-12780 | Cushion | |
| 16 | 418-54-22190 | Cushion | |
| 17 | 418-54-32870 | Cover, Under | |
| 18 | 01225-70616 | Screw, Philips Head | |
| 19 | 418-926-3490 | Washer | |
| 20 | 01225-70616 | Screw, Philips Head | |
| 21 | 418-926-3490 | Washer | |
| 22 | 423-54-42790 | Band |
