| 1 | 6219-21-4110 | Housing | |
| 2 | 6215-21-4810 | Gasket | |
| 3 | 01010-61865 | Bolt | |
| 4 | 01643-31845 | Washer | |
| 5 | 07040-13316 | Plug | |
| 6 | 07002-23334 | O-ring | |
| 7 | Seal, Oil | ||
| 8 | 6136-51-4140 | Plug | |
| 9 | 07005-02216 | Seal, Washer | |
| 10 | 6261-81-2902 | Sensor Assembly | |
| 10 | 6261-81-2901 | Sensor Assembly, Speed | |
| 10 | 6261-81-2911 | Sensor | |
| 10 | 6271-81-9220 | O-ring | |
| 11 | 01010-80820 | Bolt | |
| 12 | 01643-30823 | Washer | |
| 13 | 7861-93-2330 | Sensor, Magnetic Pick-Up | |
| 14 | 01583-02213 | Nut | |
| |$17 | 6162-23-4500 | Gear Assembly | |
| 15 | Case | ||
| 16 | Shaft | ||
| 17 | Gear | ||
| 18 | Spring | ||
| 19 | 6162-23-4531 | Pin, Snap | |
| 20 | Seal, Dust | ||
| 21 | 6162-23-4941 | Gasket | |
| 22 | 01010-81030 | Bolt | |
| 23 | 01643-31032 | Washer |
