| 1 | 6210-21-8711 | Breather | |
| 2 | 6631-11-5630 | Spacer | |
| 3 | 01010-81040 | Bolt | |
| 4 | 01010-81045 | Bolt | |
| 5 | 01643-31032 | Washer | |
| 6 | 07000-72060 | O-ring | |
| 7 | 6130-61-6611 | Hose | |
| 8 | 07285-00260 | Clip, Hose | |
| 9 | 6215-21-8610 | Tube,R.H. | |
| 10 | 01010-81220 | Bolt | |
| 11 | 01643-31232 | Washer | |
| 12 | 6215-21-8620 | Tube,L.H. | |
| 13 | 01010-81035 | Bolt | |
| 14 | 01643-31032 | Washer | |
| 15 | 6110-23-6490 | Spacer | |
| 16 | 01010-81245 | Bolt | |
| 17 | 01643-31232 | Washer | |
| 18 | 6127-92-1250 | Spacer | |
| 19 | 04434-52112 | Clip | |
| 20 | 07287-01914 | Hose | |
| 21 | 07287-01916 | Hose | |
| 22 | 07285-00220 | Clip | |
| 23 | 6218-81-4111 | Sensor Assembly, Blowby | |
| 24 | 6215-11-6320 | Connector | |
| 25 | 07000-03050 | O-ring | |
| 26 | 01435-00620 | Bolt | |
| 27 | 600-051-2100 | Clip | |
| 28 | 600-051-3100 | Clip | |
| 29 | 01010-81020 | Bolt | |
| 30 | 01643-31032 | Washer | |
| 31 | 01643-31032 | Washer | |
| 32 | 6212-65-6390 | Plate | |
| 33 | 01010-81225 | Bolt | |
| 34 | 01643-31232 | Washer | |
| 35 | 08193-20010 | Clip | |
| 36 | 01010-81016 | Bolt | |
| 37 | 01643-31032 | Washer |
