| 1 | 419-43-29110 | Bracket | |
| 2 | 01010-81240 | Bolt | |
| 3 | 130-43-64260 | Collar | |
| 4 | 08193-20010 | Clip | |
| 5 | 01010-81025 | Bolt | |
| 6 | 01643-31032 | Washer | |
| 7 | 421-43-29120 | Bracket | |
| 8 | 01010-81230 | Bolt | |
| 9 | 01643-31232 | Washer | |
| 10 | 56B-06-15610 | Switch, Proximity | |
| 11 | 423-43-39160 | Angle | |
| 12 | 01010-81240 | Bolt | |
| 13 | 01643-31232 | Washer | |
| 14 | 6113-63-1630 | Shim, T=0.2mm | |
| 14 | 6113-63-1640 | Shim, T=0.5mm |
