| 1 | 195-Y11-2310 | Bracket | |
| 2 | 01010-81225 | Bolt | |
| 3 | 01643-31232 | Washer | |
| 4 | 195-Y11-2251 | Block | |
| 5 | 01010-81270 | Bolt | |
| 6 | 01643-31232 | Washer | |
| 7 | 09479-12400 | Clip | |
| 8 | 195-Y11-2321 | Bracket | |
| 9 | 01010-81225 | Bolt | |
| 10 | 01643-31232 | Washer | |
| 11 | 04434-53212 | Clip | |
| 12 | 07095-20523 | Cushion | |
| 13 | 04434-53212 | Clip | |
| 14 | 07095-20523 | Cushion | |
| 15 | 01010-81235 | Bolt | |
| 16 | 01643-31232 | Washer | |
| 17 | 07040-11007 | Plug | |
| 18 | 07002-61023 | O-ring | |
| 19 | 198-Y11-2121 | Hose | |
| 20 | 195-54-55133 | Bracket |
