| 1 | 196-06-21210 | Tube | |
| 2 | 07213-50510 | Connector | |
| 3 | 196-06-21180 | Plate | |
| 4 | 01010-81020 | Bolt | |
| 5 | 01643-31032 | Washer | |
| 6 | 6610-81-8820 | Elbow | |
| 7 | 196-06-21190 | Tube | |
| 8 | 07213-50510 | Connector | |
| 9 | 203-62-21740 | Nipple | |
| 10 | 175-06-37560 | Block | |
| 11 | 01010-81025 | Bolt | |
| 12 | 01643-31032 | Washer | |
| 13 | 175-06-81160 | Clamp | |
| 14 | 01010-80620 | Bolt | |
| 15 | 01643-30623 | Washer | |
| 16 | 01220-40312 | Screw | |
| 17 | 01601-20307 | Washer | |
| 18 | 01220-40612 | Screw, Philips Head | |
| 19 | 01602-20619 | Washer | |
| 20 | 196-06-21250 | Bracket | |
| 21 | 01010-80820 | Bolt | |
| 22 | 01602-20825 | Washer | |
| 23 | 04434-53211 | Clip | |
| 24 | 01010-81020 | Bolt | |
| 25 | 01643-31032 | Washer | |
| 26 | 08034-00414 | Band |
