| |$0 | 17A-57-22121 | Seat Assembly | |
| 1 | AS163576 | Frame Assembly | |
| 2 | AS169769 | Back Cover Kit | |
| 3 | AS160167 | Back Seat Foam Kit | |
| 4 | AS159768 | Seat Cover Assembly | |
| 5 | AS157154 | Seat Foam Kit | |
| 6 | AS156714 | Riser Kit | |
| 7 | AS156713 | Spring Kit | |
| 8 | AS157157 | Latch Kit | |
| 9 | AS157240 | Sliderail Kit | |
| 10 | AS156717 | Up Stop and Bump Stop Kit | |
| 11 | AS157230 | Suspension Assembly | |
| 12 | AS163577 | Suspension Cover Kit | |
| 13 | AS157228 | Damper Assembly | |
| 14 | AS156737 | Weight Adjuster Kit | |
| 15 | 01252-40816 | Bolt, Hexagon Socket Head | |
| 16 | 176-57-41152 | Cover |
