| |1 | 130-919-1201 | DRAWBAR ASS'Y | |
| 1 | DRAWBAR | ||
| 2 | 09242-45145 | PIN | |
| 3 | 09242-45165 | PIN | |
| 4 | 09245-04830 | CHAIN | |
| 5 | 09245-50060 | HOOK | |
| 6 | 09249-00016 | LATCH | |
| 7 | 01012-51260 | BOLT | |
| 8 | 01590-31215 | NUT | |
| 9 | 04050-13025 | PIN | |
| 10 | 130-919-1251 | GUIDE | |
| 11 | 124-69-51160 | BRACKET,L.H. | |
| 12 | 124-69-51170 | BRACKET,R.H. | |
| 13 | 01010-82465 | BOLT | |
| 14 | 01602-22472 | WASHER | |
| 15 | 01010-82050 | BOLT | |
| 16 | 01602-22060 | WASHER | |
| 17 | 130-919-1281 | BRACKET | |
| 18 | 01011-82030 | BOLT | |
| 19 | 01602-22060 | WASHER | |
| 20 | 130-919-1291 | PIN | |
| 21 | 130-919-1320 | PIN |
