| 1 | 456-162 | PLATE | |
| 2 | 456-273 | SHAFT | |
| |3 | 452-636 | IDLER GEAR ASS'Y | |
| 3 | GEAR | ||
| 4 | 451-094 | BUSHING | |
| 5 | 455-024 | RING,SNAP | |
| 6 | 456-748 | BOLT | |
| 7 | 454-749 | BEARING | |
| 8 | 451-154 | CAM ASS'Y | |
| 9 | 453-075 | KEY | |
| 10 | 450-188 | BEARING | |
| 11 | 452-429 | FLANGE | |
| 12 | 456-708 | BOLT | |
| 13 | 450-186 | BEARING | |
| 14 | 456-750 | BOLT | |
| 15 | 455-326 | SCREW |
