| 1 | 456-162 | PLATE | |
| 2 | 456-271 | SHAFT | |
| |3 | 452-636 | IDLER GEAR ASS'Y | |
| 3 | GEAR | ||
| 4 | 451-094 | BUSHING | |
| 5 | 455-024 | RING,SNAP | |
| 6 | 456-748 | BOLT | |
| |7 | 451-155 | CAM ASS'Y | |
| 7 | CAMSHAFT | ||
| 8 | 450-188 | BEARING | |
| 9 | 450-185 | BEARING | |
| 10 | 453-074 | KEY | |
| 11 | 452-637 | GEAR | |
| 12 | 455-209 | WASHER,SPRING | |
| 13 | 454-995 | NUT | |
| 14 | 450-929 | RETAINER | |
| 15 | 455-325 | SCREW |
