| |$2 | YM129423-77200 | ALTERNATOR | |
| 1 | YMX94905-61001 | NUT | |
| 2 | YM119620-77380 | ROTOR | |
| 3 | YM119620-79240 | BEARING | |
| 4 | YM119620-79250 | RING | |
| 5 | YM119620-79360 | WASHER, THRUST | |
| 6 | YM119620-77421 | COIL, FIELD | |
| 7 | NSS | HOUSING | |
| 8 | YM119620-79200 | BEARING | |
| 9 | YM119620-79210 | PLATE | |
| 10 | YM119620-79220 | BOLT | |
| 11 | YM119620-79230 | STUD | |
| 12 | YM119620-77440 | STATOR | |
| 13 | YM129423-77450 | COVER, END | |
| 14 | YM119620-77461 | PULLEY | |
| 15 | YM119620-77471 | NUT | |
| 16 | YM129423-77710 | GOVERNOR | |
| 17 | YM119620-79260 | COVER | |
| 18 | YM119620-79270 | HOLDER, BRUSH | |
| 19 | YM119620-77480 | FLEX SHORN | |
| 20 | YM119620-79280 | SPRING | |
| 21 | YM119620-79290 | BOLT | |
| 22 | YM119620-79300 | BOLT | |
| 23 | YM119620-79310 | BOLT | |
| 24 | YM119620-79320 | BOLT | |
| 25 | YM119620-79330 | BOLT | |
| 26 | YM119620-79340 | INSULATION | |
| 27 | YM119620-79350 | NUT | |
| 28 | YM119620-77490 | COLLAR | |
| 29 | YM119620-79360 | WASHER |
