Запчасти fig. a-a регулятор spring pack погрузчики колесные wa500-1lc s/n a60001-up Komatsu



|$0 1241 685 H91 COVER - GOVERNOR SPRING PACK
1 1241 687 H1 COVER - GOVERNOR SPRING PACK
2 1241 688 H91 PLUG - THREADED
3 1239 669 H1 O-RING
4 1240 060 H1 GASKET - GOVERNOR SPRING PACK
|$5 1239 734 H91 PACK, IDLE
5 1239 705 H1 GUIDE - IDLE SPRING PLUNGER
6 1239 628 H1 SPRING, COMPRESSION
7 1240 063 H1 SCREW - KNURLED
8 1239 369 H1 BOLT - WITH WASHER
9 1238 053 H1 RING, RETAINING
10 1239 406 H1 SPRING, COMPRESSION
11 1239 370 H1 BOLT - WITH WASHER
12 1296 764 H1 PLUNGER - IDLE SPRING
13 1239 067 H1 SEAL, WIRE
14 1238 629 H1 SPACER, MOUNTING
15 1240 062 H1 WASHER, PLAIN
16 1240 064 H1 SHIM - 0.020 IN. (0.508 MM)
|$18 1240 065 H1 SHIM - 0.010 IN. (0.254 MM)
|$19 1240 066 H1 SHIM - 0.005 IN. (0.127 MM)
|$20 1238 449 H1 SHIM - 0.007 IN. (0.178 MM)
|$21 1238 511 H1 SHIM - 0.007 IN. (0.178 MM)
17 1296 765 H1 SPRING, COMPRESSION
|$23 1239 452 H91 COVER - GOVERNOR SPRING PACK
18 1239 341 H91 COVER - GOVERNOR SPRING PACK
19 1239 230 H1 BUSHING
20 1240 048 H1 O-RING
21 1238 182 H1 SCREW - ADJUSTING
22 1240 080 H1 SCREW - SET
23 1239 231 H1 SHAFT, THROTTLE
24 1240 084 H1 STOP - THROTTLE SHAFT
25 1239 233 H1 SEAL, DUST
26 1238 184 H1 NUT - FUEL PUMP ADJUSTING
27 1250 262 H1 NUT, HEX
28 1238 192 H1 WASHER, PLAIN
|$35 1237 957 H91 PACK, IDLING
29 1240 082 H1 PLUNGER, GOVERNOR
30 1240 083 H1 RING, RETAINING
31 1240 075 H1 GUIDE, SPRING
32 1238 357 H1 SPRING, COMPRESSION
33 1240 077 H1 SHIM - 0.020 IN. (0.508 MM)
|$41 1240 078 H1 SHIM - 0.010 IN. (0.254 MM)
|$42 1240 079 H1 SHIM - 0.005 IN. (0.127 MM)
34 1241 572 H1 SPRING, GOVERNOR
35 1240 085 H1 PLUNGER - THROTTLE LEVER
36 1240 060 H1 GASKET - SPRING PACK
37 1239 369 H1 BOLT - WITH WASHER
20
26
19
24
25
20
27
23
28
27
25
21
22
19
18
26
36
28
37
35
33
2
11
3
34
31
13
29
9
30
17
8
32
1
4
7
6
10
14
16
5
15
12
