Запчасти fig no. трансмиссия реверс муфта погрузчики колесные wa450-2 s/n a25001-up Komatsu



1 421-15-12112 SHAFT
2 07018-20502 RING, SEAL
3 06000-06210 BEARING
4 04064-05020 RING, SNAP
5 421-15-12140 SPACER
6 421-15-12210 GEAR
7 04064-04818 RING,SNAP
8 421-15-12310 CARRIER
9 421-15-12410 GEAR
10 09232-02932 BEARING
11 09233-02920 WASHER, THRUST
12 232-15-12530 SHAFT
13 04260-00635 BALL
14 04077-00090 RING, SNAP
15 421-15-12810 SPACER
16 06000-06922 BEARING
17 04070-00110 RING, SNAP
|$18 421-15-00110 CAGE ASSEMBLY
18 NSS CAGE
19 175-15-11230 PLUG
20 04077-00150 RING, SNAP
21 07018-12005 RING, SEAL
22 421-15-12620 GEAR, RING
23 421-15-12610 GEAR, RING
24 421-15-12750 PISTON, REVERSE
25 144-15-22881 RING, SEAL
26 569-15-12860 RING, SEAL
27 424-15-12710 DISC
28 424-15-12720 PLATE
29 421-15-11171 HOUSING, FORWARD AND REVERSE
30 232-15-11270 PIN
31 145-14-12790 SPRING
32 175-15-42880 SPRING
33 04020-01228 PIN, DOWEL
34 421-15-11250 BOLT
35 145-15-11570 WASHER
34
18
35
2
12
1
13
11
20
9
17
10
16
11
15
19
33
21
14
4
32
3
5
8
31
6
23
7
30
22
27
28
27
28
27
28
27
24
25
26
29
