Запчасти топливн. насос с rack ограничитель погрузчики колесные wa420-1lc s/n a25001-up Komatsu



1 1295 174 H91 PUMP, FUEL INJECTION
2 6742-01-5050 VALVE, OVERFLOW
3 6742-01-2080 WASHER, SEALING
4 6742-01-2110 PLUG, TIMING
5 6742-01-2120 WASHER, SEALING
6 6735-71-9110 LEVER, SHUTOFF VALVE
7 6735-71-9130 SPRING, SHUTOFF
8 6735-71-9140 HOUSING, RETURN SPRING
9 1241 266 H1 GASKET, FEED PUMP COVER
10 6742-01-2050 NUT, GEAR RETAINING
11 6742-01-2060 WASHER, LOCK
12 6735-71-9170 LEVER, CONTROL
13 1295 657 H1 SCREW, VENT
14 1295 658 H1 WASHER, SEALING
15 1295 659 H1 SCREW, VENT
16 1295 660 H1 WASHER, SEALING
17 6735-71-9120 SEAL, RECTANGULAR RING
18 6735-71-9150 COVER, FUEL PUMP
19 1307 573 H1 NUT, HEXAGON
20 6735-71-9210 WASHER, LOCK
21 6735-71-9220 WASHER, FLAT
22 6735-71-9180 BOLT, THROTTLE SHAFT
23 6742-01-4030 SEAL, O-RING
24 6733-71-5510 ELBOW, MALE ADAPTER
25 1283 364 H1 ELBOW, MALE ADAPTER
26 1241 126 H1 HOSE, FLEXIBLE
6
24
18
25
1
8
17
26
7
15
16
13
21
14
23
12
11
19
20
22
3
9
5
4
10
2
