Запчасти afc assembly погрузчики колесные wa500-1le s/n a61001-up Komatsu
|
|
|$0 |
1296 745 H91 |
ASSEMBLY, AFC
|
|
|
1 |
1239 017 H1 |
SHIM (.015 INCH)
|
|
|
|$2 |
1296 754 H1 |
SHIM, AFC
|
|
|
|$3 |
1296 755 H1 |
SHIM, AFC
|
|
|
|$4 |
1296 756 H1 |
SHIM, AFC
|
|
|
|$5 |
1296 757 H1 |
SHIM, AFC
|
|
|
2 |
1239 303 H1 |
DIAPHRAGM
|
|
|
3 |
1294 101 H1 |
O-RING
|
|
|
4 |
1294 108 H1 |
O-RING
|
|
|
5 |
1296 751 H1 |
PISTON, AFC
|
|
|
6 |
1296 752 H1 |
PISTON, AFC
|
|
|
7 |
1296 750 H1 |
NUT, LOCK (#10 - 32 UNF)
|
|
|
8 |
1296 753 H1 |
WASHER, PLAIN (1/8 INCH)
|
|
|
9 |
1294 109 H1 |
O-RING
|
|
|
10 |
1296 748 H91 |
ASSEMBLY, BARREL/PLUNGER
|
|
|
|$15 |
NSS |
PLUNGER, AFC
|
|
|
|$16 |
NSS |
BARREL, AFC
|
|
|
|$17 |
NSS |
COVER, FUEL CONTROL
|
|
|
11 |
1240 009 H1 |
CONNECTOR, MALE
|
|
|
12 |
1238 182 H1 |
BOLT (1/4 - 28x1 1/4 INCH)
|
|
|
13 |
1296 749 H1 |
COVER, FUEL CONTROL
|
|
|
14 |
1296 995 H1 |
NUT, LOCK (1/4 - 28 UNF)
|
|
|
15 |
1239 397 H1 |
SPRING, COMPRESSION
|
|
|
16 |
1238 053 H1 |
RING, RETAINING
|
|
|
17 |
1307 343 H1 |
SPRING, COMPRESSION
|
|
|
18 |
1307 344 H1 |
SPRING, COMPRESSION
|
|
|
19 |
1296 760 H1 |
RETAINER, SPRING
|
|
|
20 |
1296 759 H1 |
COVER, PROTECTIVE
|
|
|
21 |
1240 070 H1 |
BOLT, FILLISTER HEAD CAP (1/4 - 20x1 INCH)
|
|
|
22 |
1238 113 H1 |
WASHER, PLAIN (1/4 INCH)
|
21
22
11
13
14
20
12
19
18
7
8
10
5
2
6
8
17
1
16
4
9
3
15
