| 1 | 1239 675 H1 | BOLT (7/16 - 20x1 3/4 INCH) | |
| |$1 | 1246 118 H91 | PLUG, THREADED | |
| 2 | 1246 119 H1 | O-RING | |
| 3 | 1246 120 H1 | PLUG, THREADED | |
| 4 | 1296 978 H1 | BOLT (7/16 - 20x4 1/2 INCH) | |
| 5 | 1239 619 H2 | GASKET, LUBE OIL PUMP | |
| |$6 | 1307 389 H91 | PUMP, LUBRICATING OIL | |
| 6 | 1238 322 H1 | O-RING | |
| 7 | 1238 335 H1 | WASHER, PLAIN (3/8 INCH) | |
| 8 | 1238 635 H1 | PLATE, COVER | |
| 9 | 1239 195 H1 | SPRING, COMPRESSION | |
| 10 | 1239 212 H1 | BOLT (3/8 - 16x1 INCH) | |
| 11 | 1239 286 H1 | PLUG, RETAINER | |
| 12 | 1239 322 H1 | GASKET, LUBE OIL PUMP COVER | |
| 13 | 1239 481 H1 | BOLT (5/16 - 18x5/8 INCH) | |
| 14 | 1239 482 H1 | BOLT (5/16 - 18x1 INCH) | |
| |$16 | 1239 323 H2 | GEAR, LUBE OIL PUMP | |
| 15 | 1240 015 H1 | BUSHING | |
| 16 | NSS | GEAR, LUBE OIL PUMP | |
| |$19 | 1239 324 H92 | COVER, LUBE OIL PUMP | |
| 17 | 1240 036 H1 | BUSHING | |
| 18 | NSS | COVER, LUBE OIL PUMP | |
| 19 | 6736-51-9110 | GASKET, HYDRAULIC PUMP | |
| |$23 | 1307 391 H91 | PUMP, LUBRICATING OIL | |
| 20 | 1239 279 H1 | SHAFT, IDLER | |
| 21 | 1239 318 H1 | WASHER, PLAIN (3/4 INCH) | |
| 22 | 1239 319 H1 | DISC, VALVE | |
| 23 | 1239 320 H1 | SPRING, COMPRESSION | |
| 24 | 1295 894 H1 | GEAR, LUBE OIL PUMPING | |
| 25 | 1239 280 H1 | SHAFT, LUBE OIL PUMP | |
| 26 | 1307 392 H1 | GEAR, LUBRICATING OIL PUMP | |
| 27 | 1307 393 H1 | PLUG, RETAINER | |
| |$32 | 1267 842 H1 | BODY, LUBRICATING OIL PUMP | |
| 28 | NSS | BODY, LUBRICATING OIL PUMP | |
| 17 | 1240 036 H1 | BUSHING | |
| 29 | 1295 893 H1 | PLUNGER, PRESSURE REGULATOR |
