| 1 | 6211-51-8120 | TUBE, SUPPLY | |
| 2 | 07217-60813 | ELBOW | |
| 3 | 6211-51-8131 | CONNECTOR | |
| 4 | 6211-51-8170 | HOSE, SUPPLY | |
| 5 | 07214-50813 | CONNECTOR | |
| 6 | 6211-51-8110 | TUBE, DRAIN | |
| 7 | 6151-51-8150 | GASKET, DRAIN TUBE TO TURBOCHARGER | |
| 8 | 01010-51025 | BOLT | |
| 9 | 07260-22011 | HOSE, DRAIN | |
| 10 | 07281-00359 | CLAMP, HOSE | |
| 11 | 6151-51-8130 | ELBOW | |
| 12 | 6210-51-8320 | CLIP, SUPPLY HOSE | |
| 13 | 01010-51035 | BOLT | |
| 14 | 01640-21016 | WASHER | |
| 15 | 6631-11-5630 | SPACER |
