| 1 | 6150-11-5910 | MUFFLER | |
| 1 | 6150-11-5511 | MUFFLER | |
| 1 | 6150-11-5510 | MUFFLER | |
| 2 | 6150-11-5710 | GASKET (K1) | |
| 3 | 01010-61030 | BOLT | |
| 4 | 01050-61045 | BOLT | |
| 5 | 6114-11-5590 | NUT | |
| 6 | 6150-11-5720 | BRACKET | |
| 6 | 6150-11-5430 | BRACKET | |
| 6 | 6150-11-5720 | BRACKET | |
| 7 | 01010-31040 | BOLT | |
| 8 | 6631-11-5630 | SPACER | |
| 9 | 01010-31025 | BOLT | |
| 10 | 01580-01008 | NUT | |
| 11 | 6150-11-5561 | TUBE | |
| 11 | 6150-11-5570 | TUBE | |
| 11 | 6150-11-5561 | TUBE | |
| 12 | 01010-51035 | BOLT | |
| 13 | 6151-11-5590 | PIPE,EXHAUST | |
| 14 | 6138-11-5620 | CLAMP | |
| 15 | 6693-12-5550 | BOLT | |
| 16 | 01582-01411 | NUT | |
| 17 | 6151-11-5670 | WASHER |
