| 1 | 1268 090 H1 | BRACKET, BELT TENSIONER | |
| 2 | 1295 443 H1 | TENSIONER, BELT | |
| 3 | 1240 258 H1 | BOLT | |
| 4 | 1240 204 H1 | BOLT | |
| |$4 | 1240 852 H91 | SUPPORT ASSEMBLY, FAN | |
| 5 | 1240 410 H1 | RETAINER, SHAFT | |
| 6 | NSS | SUPPORT, SHAFT | |
| 7 | 1240 406 H1 | HUB, FAN | |
| 8 | NSS | SHAFT, FAN DRIVE | |
| 9 | 1240 405 H1 | BOLT | |
| 10 | 1277 006 H1 | PULLEY, FAN | |
| 11 | 1295 290 H1 | BELT, V-RIBBED | |
| 12 | 1240 141 H1 | BOLT |
