Запчасти turbo lube грейдеры gd530a/aw-2a/2b/2c w/s6d102 s/n 202002-up Komatsu
|
|
|$0 |
1433 314 H91 |
LUBE INSTALLATION, TURBO
|
|
|
|$1 |
1270 003 H91 |
KIT, TURBO LUBE
|
|
|
1 |
1433 618 H1 |
TANK, OIL ACCUMULATOR
|
|
|
|$3 |
1433 619 H1 |
ADAPTOR ASSEMBLY
|
|
|
2 |
1433 614 H1 |
BRACKET, MOUNTING
|
|
|
3 |
1433 612 H1 |
HOSE
|
|
|
4 |
1433 611 H1 |
VALVE, ONE-WAY CHECK
|
|
|
5 |
156 764 H1 |
CLAMP
|
|
|
6 |
31 066 R1 |
BOLT
|
|
|
7 |
78 825 |
SPACER
|
|
|
8 |
1281 698 H1 |
SUPPORT
|
|
|
9 |
25 222 R1 |
BOLT
|
|
|
10 |
25 532 R1 |
WASHER, FLAT
|
|
|
11 |
25 519 R1 |
NUT, HEX
|
|
|
12 |
1285 161 H1 |
HOSE
|
|
|
13 |
444 319 |
REDUCER
|
|
|
14 |
9402 864 |
ELBOW, STREET - 90°
|
|
|
15 |
86 191 |
BUSHING, REDUCER
|
|
|
16 |
112 826 |
ADAPTOR, REDUCING
|
|
|
17 |
1433 802 H1 |
PLATE, DECAL
|
|
|
|$20 |
1433 778 H1 |
DECAL - TURBO LUBE
|
|
|
N/I |
1431 123 H1 |
PLUG - IN ENGINE BLOCK WHERE HOSE WAS REMOVED
|
11
10
8
9
11
20
19
1
16
15
10
4
13
2
5
9
7
3
6
14
12
3
17
18
