Запчасти awd насос поворотн. группа грейдеры gd530a/aw-2a/2b/2c w/s6d102 s/n 202002-up Komatsu
|
|
|$0 |
134 581 |
ROTARY ASSEMBLY
|
|
|
1 |
NSS |
RING, MECHANICAL STOP
|
|
|
2 |
NSS |
RING, SPRING
|
|
|
3 |
NSS |
RING, RETAINING
|
|
|
|$4 |
134 303 |
KIT, SEAL
|
|
|
4 |
NSS |
O-RING
|
|
|
5 |
1434 114 H1 |
FRONT COVER
|
|
|
6 |
1434 281 H1 |
SEAL, OIL
|
|
|
7 |
NSS |
O-RING
|
|
|
8 |
NSS |
RING, RETAINING
|
|
|
9 |
NSS |
DISC, SUPPORTING
|
|
|
10 |
NSS |
SPACER
|
|
|
11 |
NSS |
SHIMS
|
|
|
12 |
1434 117 H1 |
DISC, SUPPORTING
|
|
|
13 |
1434 115 H1 |
SHIMS
|
|
|
14 |
1434 116 H1 |
SHIMS
|
|
|
15 |
NSS |
BEARING, ROLLER
|
|
|
16 |
1434 103 H1 |
SHAFT, DRIVE
|
|
|
17 |
1434 111 H1 |
FLANGE, BEARING
|
|
|
18 |
1434 112 H1 |
BEARING SET, CAGE
|
|
|
19 |
NSS |
HUB, CLUTCH
|
|
|
20 |
NSS |
PIECE, SLIDING
|
|
|
21 |
NSS |
CRADLE WITH PIN
|
|
|
22 |
1434 113 H1 |
WIRE
|
|
|
23 |
NSS |
PIN
|
|
|
24 |
NSS |
STOP, MECHANICAL
|
|
|
25 |
NSS |
SCREW, COUNTERSUNK
|
|
|
26 |
1434 100 H1 |
PISTON
|
|
|
27 |
1434 101 H1 |
PLATE, RETAINING
|
|
|
28 |
1434 105 H1 |
BALL, RETAINING
|
|
|
29 |
NSS |
SPRING, CUP
|
|
|
30 |
1434 107 H1 |
SHIMS
|
|
|
|$32 |
1434 108 H1 |
SHIMS
|
|
|
|$33 |
1434 109 H1 |
SHIMS
|
|
|
|$34 |
1434 110 H1 |
SHIMS
|
|
|
31 |
NSS |
CYLINDER WITH BUSHING
|
|
|
32 |
134 582 |
PLATE, CONTROL
|
|
|
33 |
1434 104 H1 |
BEARING, ROLLER
|
|
|
34 |
NSS |
RING, SPRING
|
21
18
17
7
20
16
15
13
11
10
22
8
6
18
24
5
23
4
25
3
19
1
9
14
12
9
9
34
2
33
32
31
30
29
28
27
26
