Запчасти двойн. counterbalance и разгруз. клапан сцепное устройство lift грейдеры gd530a/aw-2b/2c w/s6d102e s/n 203163-up Komatsu
|
|
|$0 |
1261 134 H92 |
VALVE, DUAL COUNTERBALANCE AND RELIEF
|
|
|
1 |
NSS |
BLOCK, VALVE
|
|
|
2 |
1440 166 H91 |
CARTRIDGE, COUNTERBALANCE
|
|
|
|$3 |
1257 988 H1 |
KIT, SEAL
|
|
|
3 |
NSS |
RING, BACK-UP
|
|
|
4 |
NSS |
O-RING
|
|
|
5 |
NSS |
RING, BACK-UP
|
|
|
6 |
NSS |
RING, BACK-UP
|
|
|
7 |
NSS |
O-RING
|
|
|
8 |
1257 989 H1 |
CARTRIDGE, RELIEF VALVE
|
|
|
|$10 |
1257 990 H1 |
KIT, SEAL
|
|
|
9 |
NSS |
O-RING
|
|
|
10 |
NSS |
RING, BACK-UP
|
|
|
11 |
NSS |
RING, BACK-UP
|
|
|
12 |
NSS |
O-RING
|
8
9
10
11
12
1
7
6
5
4
3
2
2
