Запчасти all колеса привод насос - управл-е module assembly грейдеры gd530a/aw-2b/2c w/s6d102e s/n 203163-up Komatsu
|
|
|$0 |
1440 344 H91 |
CONTROL MODULE ASSEMBLY
|
|
|
1 |
1440 345 H1 |
MODULE, CONTROL
|
|
|
2 |
NSS |
LEVER, FEEDBACK
|
|
|
3 |
NSS |
SHIM
|
|
|
4 |
NSS |
NEEDLE ROLLER
|
|
|
5 |
NSS |
CONTROL PISTON WITH CYLINDER PIN
|
|
|
6 |
1438 718 H1 |
ARM, LEVER
|
|
|
7 |
NSS |
PIN, ECCENTRIC
|
|
|
8 |
NSS |
SHIM
|
|
|
9 |
NSS |
SCREW, SOCKET-HEAD
|
|
|
10 |
NSS |
SCREW, SOCKET-HEAD
|
|
|
11 |
NSS |
PIN, DOUBLE BREAK
|
|
|
12 |
NSS |
O-RING
|
|
|
13 |
1438 707 H1 |
COVER
|
|
|
14 |
1440 346 H1 |
SPRING, DRAW
|
|
|
15 |
1440 347 H1 |
GASKET
|
|
|
16 |
1440 348 H1 |
ASSEMBLY PIECE
|
|
|
17 |
1440 349 H1 |
SCREW, SOCKET-HEAD
|
|
|
18 |
1440 350 H1 |
SCREW, SOCKET-HEAD
|
|
|
19 |
1440 351 H1 |
O-RING
|
|
|
20 |
1440 352 H1 |
O-RING
|
|
|
21 |
1440 353 H1 |
SOLENOID, PROPORTIONAL
|
|
|
22 |
1440 319 H1 |
O-RING
|
|
|
23 |
1440 354 H1 |
O-RING
|
|
|
24 |
1440 355 H1 |
O-RING
|
|
|
25 |
1440 356 H1 |
SPRING, CUP
|
|
|
26 |
1440 357 H1 |
PLUG, SOLENOID - BLACK
|
|
|
27 |
134 313 |
PLUG, SOLENOID - GRAY
|
|
|
28 |
1440 358 H1 |
PIN, CYLINDER
|
26
10
7
8
21
12
16
9
25
24
18
22
23
13
3
15
14
6
1
11
28
4
20
2
19
27
5
24
25
16
17
21
