Запчасти all колеса привод насос - поворотн. группа грейдеры gd530a/aw-2b/2c w/s6d102e s/n 203163-up Komatsu



|$0 1440 308 H91 ROTARY GROUP, AWD PUMP
1 1440 309 H1 CYLINDER WITH CONTROL PLATE
2 NSS END PLATE
3 1438 670 H1 PISTON
4 1438 671 H1 PLATE, RETAINING
5 1438 672 H1 PLATE, SWASH
6 1438 673 H1 BALL, RETAINING
7 1438 674 H1 SPRING STACK, CUP
8 1438 716 H1 SHIM, PRELOAD - 0.047 IN. (1.20 MM)
|$9 1438 675 H1 SHIM, PRELOAD - 0.037 IN. (0.95 MM)
|$10 1438 676 H1 SHIM, PRELOAD - 0.031 IN. (0.80 MM)
|$11 1438 677 H1 SHIM, PRELOAD - 0.024 IN. (0.60 MM)
9 1438 678 H1 RACE, BEARING
10 1438 679 H1 BEARING SET, CRADLE
11 1438 680 H1 WIRE
12 1438 681 H1 LEVER
13 1438 682 H1 SHIM
14 1438 683 H1 SPRING
15 1440 313 H1 RING, RETAINING
16 1440 311 H1 RING, RETAINING
17 1440 312 H1 SEAL, SHAFT
18 1438 684 H1 SHAFT
19 1434 104 H1 BEARING
20 1440 310 H1 RING, RETAINING
20
19
18
16
17
16
3
12
11
10
9
5
11
10
9
2
15
13
14
13
1
7
8
6
4
X
