Запчасти корпус передачи грейдеры gd530a/aw-2b/2c w/s6d102e s/n 203163-up Komatsu



|$0 160 867 H45 CASE ASSEMBLY, TRANSFER
1 77 572 RING, RETAINING
2 107 771 RING, RETAINING
3 119 750 BEARING, BALL
4 158 204 GEAR, OUTPUT
5 157 995 BEARING, ROLLER
6 160 873 HOUSING, TRANSFER CASE
7 160 870 GEAR, TRANSFER CASE
8 160 871 CONE, BEARING
9 108 138 CUP, BEARING
10 160 875 RING, RETAINING
11 160 869 GEAR, TRANSFER CASE
12 160 987 SHIM - 0.005 IN. (0.127 MM)
|$13 160 988 SHIM - 0.007 IN. (0.178 MM)
|$14 160 989 SHIM - 0.020 IN. (0.508 MM)
13 160 874 PLATE, RETAINING
14 82 762 BOLT
5
4
3
2
6
1
10
9
8
7
14
13
12
11
8
9
