Запчасти moldboard цилиндр перекоса линия актуатораs грейдеры gd530a/aw-2b/2c w/s6d102e s/n 203163-up Komatsu



2 570 828 R1 O-RING
3 587 639 R1 CONNECTOR, REDUCING
4 1258 731 H1 HOSE
5 160 927 SLEEVE - 25 IN
6 1430 788 H1 HOSE
|$6 160 926 SLEEVE - 22 IN
7 1439 446 H1 HOSE
|$8 160 926 SLEEVE - 22 IN
9 160 927 SLEEVE - 36 IN
11 59 199 CONNECTOR
12 364 885 R1 O-RING
13 61 569 ELBOW - 90 DEGREE
14 58 853 O-RING
15 1285 719 H1 HOSE
16 129 083 R1 CLAMP
17 140 483 H BOLT
18 25 534 R1 WASHER, FLAT
19 25 522 R1 NUT, HEX
20 935 036 R91 ELBOW - 90 DEGREE
21 570 828 R1 O-RING
23 25 234 R1 BOLT
24 27 326 R1 WASHER, FLAT
25 25 520 R1 NUT, HEX
26 9411 105 ELBOW - 45 DEGREE
27 570 828 R1 O-RING
28 9410 307 TEE
29 1285 713 H1 HOSE
30 1285 714 H1 HOSE
31 9410 307 TEE
32 9410 203 CONNECTOR
33 570 828 R1 O-RING
34 1285 715 H1 HOSE
35 161 448 SLEEVE
36 9410 202 CONNECTOR
37 364 839 R1 O-RING
39 9411 104 ELBOW - 45 DEGREE
40 364 839 R1 O-RING
41 116 242 CLAMP
42 08034-20519 BAND
34
36
37
29
4
39
3
2
40
1
35
4
42
30
34
3
42
38
34
2
31
35
34
32
29
28
33
26
17
39
27
36
20
18
40
37
15
41
23
21
24
16
20
8
38
5
24
21
18
25
22
13
15
19
6
15
13
4
17
6
9
14
18
14
41
13
8
16
11
8
4
12
7
15
14
13
8
18
12
19
9
10
11
7
8
14
13
