| |$0 | 1241 236 H91 | SUPPORT ASSEMBLY, FAN | |
| 1 | NSS | SUPPORT, FAN | |
| 2 | 1240 859 H1 | BEARING, BALL | |
| 3 | 1258 959 H1 | HUB, FAN | |
| 4 | 1240 854 H1 | RETAINER, FAN HUB | |
| 5 | 1240 817 H1 | BOLT | |
| 6 | 1240 144 H1 | BOLT | |
| 7 | 1241 090 H2 | PULLEY, FAN | |
| 8 | 1287 372 H1 | BRACKET, BELT TENSIONER | |
| 9 | 1240 204 H1 | BOLT | |
| 10 | 1295 443 H1 | TENSIONER, BELT | |
| 11 | 1240 258 H1 | BOLT | |
| 12 | 1257 782 H1 | BELT, V-RIBBED | |
| 13 | 1240 966 H1 | BOLT |
