Запчасти топливн. насос грейдеры gd650a-1/aw-1 s/n 200840-202000 Komatsu
|
|
1 |
1295 522 H91 |
PUMP, FUEL
|
|
|
1 |
1241 260 H1 |
VALVE, OVERFLOW
|
|
|
2 |
1241 261 H1 |
WASHER, SEALING
|
|
|
3 |
1241 262 H1 |
PLUG, TIMING
|
|
|
4 |
1241 263 H1 |
WASHER, SEALING
|
|
|
5 |
1241 240 H1 |
LEVER, SHUTOFF VALVE
|
|
|
6 |
1241 264 H1 |
SPRING, SHUTOFF
|
|
|
7 |
1241 265 H1 |
HOUSING, RETURN SPRING
|
|
|
8 |
1241 266 H1 |
GASKET, FEED PUMP COVER
|
|
|
9 |
1241 267 H1 |
NUT, GEAR RETAINING
|
|
|
10 |
1241 268 H1 |
WASHER, LOCK
|
|
|
11 |
1241 275 H1 |
LEVER, CONTROL
|
|
|
12 |
1295 657 H1 |
SCREW, VENT
|
|
|
13 |
1295 658 H1 |
WASHER, SEALING
|
|
|
14 |
1295 659 H1 |
SCREW, VENT
|
|
|
15 |
1295 660 H1 |
WASHER, SEALING
|
|
|
16 |
1283 365 H1 |
SEAL, RECTANGULAR RING
|
|
|
17 |
1283 363 H1 |
COVER, FUEL PUMP
|
|
|
18 |
1296 799 H1 |
NUT, HEXAGON
|
|
|
19 |
1240 796 H1 |
LOCKWASHER
|
|
|
20 |
1296 800 H1 |
WASHER, FLAT
|
|
|
21 |
1307 345 H1 |
SCREW
|
|
|
22 |
1241 233 H1 |
O-RING
|
|
|
23 |
1240 010 H1 |
ELBOW, MALE ADAPTER
|
|
|
24 |
1283 364 H1 |
ELBOW, MALE ADAPTER
|
|
|
25 |
1241 126 H1 |
HOSE, FLEXIBLE
|
5
23
7
24
17
16
6
25
14
15
12
13
11
22
21
10
18
19
2
9
20
1
8
3
4
