Запчасти нижн. сиденье кондиц. воздуха/обогреватель. evaporator грейдеры gd650a-1/aw-1 s/n 200840-202000 Komatsu
|
|
|$0 |
1431 388 H91 |
AIR CONDITIONER/HEATER, UNDER SEAT
|
|
|
1 |
1431 223 H1 |
HOUSING
|
|
|
2 |
1431 229 H1 |
FOAM, GRILL SEAL
|
|
|
3 |
1431 232 H1 |
FOAM, HOUSING BOTTOM
|
|
|
4 |
1431 230 H1 |
FOAM, COIL SEAL
|
|
|
|$5 |
1431 256 H91 |
COIL & PAN ASSEMBLY
|
|
|
|$6 |
1431 257 H91 |
COIL ASSEMBLY
|
|
|
5 |
1431 258 H1 |
COIL, EVAPORATOR/HEATER
|
|
|
6 |
1431 259 H1 |
VALVE, EXPANSION
|
|
|
|$9 |
72 865 |
O-RING
|
|
|
|$10 |
54 160 |
O-RING
|
|
|
|$11 |
274 085 R91 |
CLAMP, HOSE
|
|
|
7 |
1431 262 H1 |
FOAM, DRAIN PAN
|
|
|
8 |
1431 263 H1 |
PAN, DRAIN
|
|
|
9 |
1431 228 H1 |
FOAM, COVER
|
|
|
10 |
1431 227 H1 |
COVER
|
|
|
11 |
26 309 R1 |
BOLT
|
|
|
12 |
1431 264 H1 |
HOSE ASSEMBLY
|
|
|
13 |
1431 265 H1 |
HOSE ASSEMBLY
|
|
|
16 |
1251 485 H1 |
GRILL, HEATER OUTLET
|
|
|
|$22 |
24 210 R1 |
SCREW, SELF-TAPPING
|
11
10
9
6
4
12
5
7
15
13
8
1
14
3
2
16
