Запчасти lube маслоохладитель грейдеры gd650a/aw-2a/2b/2c & gd670a/aw-2a/2b/2c w/ s6d114 s/n 202002-up Komatsu



1 1241 100 H1 SPRING, COMPRESSION
2 1295 154 H1 O-RING
3 6732-11-1930 PLUG, PIPE
4 6732-11-1920 PLUG, PIPE
5 1295 176 H1 PLUG, PIPE
6 1295 152 H1 O-RING
7 1295 224 H1 FILTER, LUBE OIL (11.5 IN LONG)
8 1295 146 H1 BOLT (M8x1.25x65)
9 1241 216 H2 GASKET, OIL COOLER CORE
10 1241 004 H2 CORE, LUBE OIL COOLER
11 1304 942 H1 GASKET, LUBE OIL COOLER COVER
12 1294 829 H1 PLUNGER, PRESSURE REGULATOR
13 1238 209 H1 DOWEL, PIN
14 1295 738 H1 GASKET, FILTER HEAD
15 1240 194 H2 VALVE, BYPASS
16 6732-21-6610 BOLT (M8x1.25x25)
17 1295 149 H1 HEAD, LUBE OIL FILTER
18 1295 177 H91 COVER, LUBE OIL COOLER
19 1295 151 H92 THERMOSTAT, OIL
20 1295 153 H91 PLUG, THREADED
19
3
4
6
18
14
15
13
8
10
11
17
9
16
5
7
12
1
2
20
X
