| 1 | 1433 418 H2 | SUPPORT | |
| |$2 | 1433 596 H91 | CABLE, GROUND | |
| |$3 | 935 522 C1 | STRAP, TIE | |
| 3 | 282 437 R91 | SWITCH, REVOLVING LIGHT | |
| 4 | 713 142 C1 | CABLE - SWITCH TO BREAKER | |
| 5 | 714 248 C1 | BREAKER, CIRCUIT - 10 AMP | |
| 6 | 1106 459 H1 | BAR, BUSS | |
| 7 | 140 483 H | BOLT | |
| 8 | 25 534 R1 | WASHER, FLAT | |
| 9 | 9413 979 | NUT, LOCK | |
| 10 | 1433 417 H2 | ANGLE | |
| 11 | 120 408 | GROMMET | |
| |$13 | 117 964 | GROMMET | |
| |$14 | 638 896 C1 | SEALANT, SILICONE | |
| 12 | 1433 417 H2 | ANGLE | |
| 13 | 30 196 | PIN | |
| 14 | 1433 415 H1 | BAR | |
| 15 | 139 355 | PIN, HAIR |
