| 1 | 20Y-954-6132 | Guard | |
| 2 | 20Y-954-6171 | Bracket | |
| 3 | 20Y-954-6181 | Bracket | |
| 4 | 01011-D1245 | Bolt | |
| 5 | 01643-71232 | Washer | |
| 6 | 20Y-954-6192 | Spacer | |
| 7 | 01011-D1245 | Bolt | |
| 8 | 01643-71232 | Washer | |
| 9 | 20Y-954-6142 | Guard | |
| 10 | 01010-D1275 | Bolt | |
| 11 | 01643-71232 | Washer | |
| 12 | 20Y-954-6151 | Bracket | |
| 13 | 20Y-954-6161 | Bracket | |
| 14 | 01010-D1220 | Bolt | |
| 15 | 01643-71232 | Washer | |
| 16 | 01010-D0640 | Bolt | |
| 17 | 01643-70623 | Washer | |
| 18 | 01010-D1245 | Bolt | |
| 19 | 01643-71232 | Washer | |
| 20 | 14X-911-1330 | Hinge | |
| 21 | 01010-D1025 | Bolt | |
| 22 | 01643-71032 | Washer | |
| 23 | 20Y-54-36342 | Gas Spring Assembly | |
| 24 | 22B-954-1840 | Plate | |
| 25 | 22B-954-1660 | Plate | |
| 26 | 01010-D0820 | Bolt | |
| 27 | 01643-70823 | Washer | |
| 28 | 04052-10833 | Pin, Snap | |
| 29 | 01643-70823 | Washer |
