Запчасти масляный поддон экскаваторы pc650-3 & pc650lc-3 s/n a15001-up Komatsu
|
|
1 |
1294 627 H1 |
PAN, OIL
|
|
|
2 |
1239 159 H1 |
PLUG, PIPE
|
|
|
3 |
1239 161 H1 |
PLUG, PIPE
|
|
|
4 |
1294 537 H91 |
TUBE, LUBE OIL SUCTION
|
|
|
5 |
1238 027 H1 |
BOLT - 3/8-24 X 1
|
|
|
6 |
25 544 R1 |
WASHER, PLAIN
|
|
|
7 |
1238 108 H1 |
WASHER, LOCK
|
|
|
8 |
1238 250 H1 |
NUT, LOCK
|
|
|
9 |
1238 279 H1 |
BOLT - 7/16-14 X 4 1/2
|
|
|
10 |
1239 156 H1 |
GASKET, OIL SUCTION CONNECTION
|
|
|
11 |
1239 212 H1 |
BOLT - 3/8-16 X 1
|
|
|
12 |
1294 536 H1 |
BRACE, TUBE
|
|
|
13 |
1239 883 H1 |
CLIP
|
|
|
14 |
1241 372 H1 |
ADAPTER, OIL PAN
|
|
|
15 |
1239 759 H1 |
BOLT, W/WASHER - 3/8-16 X 1 1/4
|
|
|
18 |
1241 368 H1 |
COVER, OIL PAN ADAPTER
|
|
|
19 |
1241 379 H1 |
GASKET, ADAPTER
|
|
|
20 |
1239 243 H1 |
BAFFLE, OIL PAN
|
|
|
21 |
1238 744 H1 |
PLUG, OIL DRAIN
|
|
|
22 |
1241 299 H1 |
BOLT - 1/2-20 X 3/4
|
|
|
23 |
1294 535 H1 |
WASHER, SEALING
|
10
13
11
7
6
9
4
12
6
11
13
6
5
8
19
18
14
22
23
1
15
21
11
20
2
3
