| |$0 | 1295 191 H92 | BLOCK ASSEMBLY, CYLINDER | |
| 1 | 1296 769 H1 | BLOCK, CYLINDER | |
| 2 | 1246 122 H1 | DOWEL, PIN - No. 4 only | |
| 3 | 1238 448 H1 | PLUG, RETAINER | |
| 4 | 1239 318 H1 | WASHER, PLAIN | |
| 5 | 1239 319 H1 | DISC, VALVE | |
| 6 | 1239 320 H1 | SPRING, BYPASS VALVE | |
| 7 | 1294 031 H1 | BUSHING, CAMSHAFT | |
| 8 | 6732-61-2240 | PLUG, PIPE - (1/4 NPT) | |
| 9 | 1246 121 H1 | SEAT, PRESSURE REG VALVE | |
| |$10 | 1246 125 H91 | KIT, MAIN BEARING CAP - No. 4 only | |
| 10 | 1294 116 H1 | CAP, MAIN BEARING - No. 4 only | |
| 11 | 1246 127 H1 | PIN, ROLL | |
| 10 | 1246 128 H1 | CAP, MAIN BEARING - No. 1,2,3,5,6,7 | |
| 12 | NSS | BOLT | |
| 13 | 1246 117 H2 | STUD (M10x1.50x50MM) | |
| 14 | 1240 051 H1 | DOWEL, PIN (5/16x1/2 INCH) | |
| 15 | 1246 112 H1 | DOWEL, PIN (7/16x1 INCH) | |
| 16 | 6736-21-1820 | PLUG, EXPANSION (1.00 INCH) | |
| 17 | 1239 144 H1 | PLUG, EXPANSION (.387MM) | |
| 18 | 1246 114 H1 | DOWEL, PIN (6.00x12.00MM) | |
| 19 | 6732-11-1910 | PLUG, PIPE (1/2 NPT) | |
| 20 | 1246 116 H1 | DOWEL, RING (19.23MM) | |
| 20 | 1246 134 H1 | DOWEL, PIN (USED WHEN HYD DRIVE IS NOT REQ.) | |
| |$24 | 1246 118 H91 | PLUG, THREADED (9/16 - 18 INCH) | |
| 21 | 1246 120 H1 | PLUG, THREADED | |
| 22 | 1246 119 H1 | O-RING | |
| |$27 | 1246 131 H91 | PLUG, THREADED (3/4-16 INCH) | |
| 23 | 1246 132 H1 | PLUG, THREADED | |
| 24 | 6735-21-4160 | O-RING | |
| 25 | 1296 124 H1 | SENSOR, VISCOSITY | |
| 26 | 1246 124 H1 | WASHER, PLAIN | |
| 27 | 1296 126 H1 | PLUNGER, PRESSURE REGULATOR | |
| 28 | 1239 195 H1 | SPRING, COMPRESSION | |
| 29 | 1246 137 H1 | PLUG, RETAINER |
